Product_Category
储能系统电池储能
制造商
类型
封装
RoHS
YES
价格
| Capacity: | 9600/10240 | Model No.: | TRD-LR48200 |
|---|---|---|---|
| Operating Temperature: | -20℃ To +60℃ | Size: | L442xW580xH220 |
| Weight: | 88/92Kg | ||
| Highlight: |
Rack Mounted ESS Battery Storage,Phosphate Drop In Lead Acid Replacement,Phosphate ESS Battery Storage |
||
| Item | Spec |
| Model No. | TRD-LR48200 |
| Nominal Voltage(V) | 48/51.2 |
| Nominal Capacity(Ah) | 200 |
| Energy(Wh) | 9600/10240 |
| Dimension(mm) | L442xW580xH220 |
| Weight(Kg) | 88/92 |
| Discharge Cut-off Voltage(V) | 40.5(15S)/43.2(16S) |
| Charge Cut-off Voltage(V) | 54.7(15S)/58.4(16S) |
| Communication Port | R5485,R5232 CAN |
| Cell serial numbert(pcs | 15S/16S |
| Working Temperature | -10°C~60°C |
| Design life | 10+Years (25°C/77°F) |
| Cycle Life | >6000,25°C/77°F,80%DOD |
| Certification | CE/UN38.3 |
| Maximum continuous charge current | 100A |
| Maximum continuous discharge current | 100A |
