Specifications



Product Technical Parameters:



Item Spec
Model No. RD-LR48200
Nominal Voltage(V) 48/51.2
Nominal Capacity(Ah) 200
Energy(Wh) 9600/10240
Dimension(mm) L442xW580xH185
Weight(Kg) 88/92
Discharge Cut-off Voltage(V) 40.5(15S)/43.2(16S)
Charge Cut-off Voltage(V) 54.7(15S)/58.4(16S)
Communication Port RS485,RS232 CAN
Cell serial numbert(pcs 15S/16S
Working Temperature -10°C~60°C
Design life 10+Years (25°C/77°F)
Cycle Life >6000,25°C/77°F,80%DOD
Certification CE/UN38.3
Maximum continuous charge current 100A
Maximum continuous discharge current 100A
